Product Descriptions
>> Descriptions:
- This crawler tractor is built with triangle track design. It is adopted differential steering to have 360° in-situ turn to make it more flexible working in the muddy and paddy land.
- The control lever is within easy reach to make the job easier and driving more comfortable.
- Flat floor increases the working space enough wide and work easier.
>> Features:
- Differential steering to make tractor 360° in-situ turn
- High ground clearance to make the tractor easy get over in the field.
- Three point linkage to attach to diferent attachment like rotary tiller, harrow, ditcher etc and front can be attahced the front loader, front blade etc.
>> Technical Data
| Model NO. | T1000C |
| Tractor power | 100hp |
| General Data | |
| Type | Crawler tractor |
| Overall dimensions | 4100×1850×2980mm( to top of Rop) |
| wheel base | 1400mm |
| track tread | 1300mm |
| track tread | 1300mm |
| min ground clearance | 560（bottom of beam） |
| Min service quality | 2945Kgs |
| front ballast weight | 120Kgs |
| Transmission box | 12F+12R |
| Main gear shift | 4 |
| Auxiliary gear shift | 3×(1+1） |
| Max theoretical speed | 17.24km/h |
| The theoretical speed of forward speed | L:1. 22,1.80,2.92,3.84km/h |
| H:5.50,8.08,13.13,17.24km/h | |
| Engine Data | |
| Type | Inline, four stroke, water cooled |
| Manufacturer | YTO |
| Intake method | turbocharged |
| Cylinder NO. | 4 |
| Rated power | 73.6kW |
| Engine speed | 2300r/min |
| Track material | rubber |
| track width | 400mm |
| Working Part | |
| Suspension type | rear positioned three point linkage catergory II |
| Group No. of hydraulic valve | 2 |
| PTO speed | 540/760 r/min |
