Product Descriptions
We Cooperate with Domestic Well-known Brand Tractor Parts Suppliers, such as: Gearboxes are Assembled by Ourselves, the Gears Inside are Made of Hangzhou Gears brand, the Bearings are Harbin Brand, the Engines are Xichai, Yuchai or YTO brand, and the Clutches are YTO ZC brand, the Hood and Cab is Equipped with Zhongyuan Brand, and the Tires use Taishan Or Xulun Brand etc
|
No
|
Item
|
Data
|
Item
|
Data
|
|
1
|
Model
|
754
|
Drive type
|
4wd
|
|
2
|
Starting
|
electric
|
Clutch
|
dual stage
|
|
3
|
Engine brand
|
Xinchai euro 5
|
Engine cylinders
|
4
|
|
4
|
Rated power/speed
|
55.1/2300kw/rpm
|
Engine air
|
nature
|
|
5
|
Shift
|
12+12 shuttle
|
Front speed
|
2.46-32.73km/h
|
|
6
|
Rear speed
|
2.15-28.69km/h
|
Brake
|
disc type
|
|
7
|
Fuel tank
|
60L
|
Steering
|
hydraulic steering
|
|
8
|
Linkage
|
three point
|
Suspension type
|
categoryI or II
|
|
9
|
PTO
|
540/760/1000
|
PTO spline size
|
6 or 8
|
|
10
|
Front tyre
|
8.3-20/9.5-24
|
Rear tyre
|
12.4-28/14.9-30
|
|
11
|
Front ballast
|
yes
|
Rear ballast
|
yes
|
|
12
|
Swing draw bar
|
selectable
|
PTO cover
|
selectable
|
|
13
|
Air pump
|
selectable
|
Roll bar
|
selectable
|
|
14
|
Sun-shade
|
Yes
|
Cabin
|
selectable
|
|
15
|
Heater
|
yes
|
AC
|
yes
|
|
16
|
Min turning radius
|
≤4.0m
|
Hydraulic output
|
2 groups
|
|
17
|
Cover hood
|
metal
|
Overall dimensions
|
4020*1600*2500mm
|
|
18
|
Front wheel track
|
1250-1450mm
|
Rear wheel track
|
1350-1550mm
|
|
19
|
Wheel base
|
2040mm
|
Ground clearance
|
310-400mm
|
|
20
|
Rated traction force
|
16kn
|
Weight
|
2640kgs
|
