Product Descriptions
1.The Chinese tractors price adopt YUCHAI/YTO famous diesel engine,good reliability, large torque reserve,low fuel consumption, high economic benefits.
2.Wheel tractor farm tractor 4wd are equipped 12inch double clutch, high transfer ability, reliable effect, operation more comfortable.
3.Gear box of farming equipment tractors use F16+R8(with creeper gear), gear are reasonable,high working efficiency.
4.Tractors with plough adopt independent power output device,steady transmission,large bearing capacity.
5.Agricultural tractors with rice cultivation use disc brakes,large braking torque,good braking effecting.
6.Tractors sale New Zealand use forced type lifter, reliable use, convenient maintenance.
7.Final drive adopts planetary reduction structure,compact structure, large reduction ratio.
| Basic configuration | |||
| Model | 850/854 | ||
| Dimensions | Length×Width×Height(mm) | 4280×2085×2925 | |
| Wheel Tread(mm) | Front Wheel(mm) | 1610—1820(4WD) /1520—1820(2WD) | |
| Rear Wheel(mm) | 1620—2020 | ||
| Min.Ground Clearance(mm) | 370—450 | ||
| Dry Mass | With Cab(kg) | 3635(2WD) 3785(4WD) | |
| Without Cab(kg) | 3420(2WD) 3570(4WD) | ||
| Engine | Trade Mark or Brand | YTO/YUCHAI | |
| Engine Model | Vertical Water Cooled 4-stroke | ||
| Directly Injection | |||
| Number of Cylinder | 4 | ||
| Cooling System Type | Water Cooled | ||
| Rated Power(kw) | 62.5KW | ||
| Max. Torsion(N.M) | 330 | ||
| Rated Speed(r/min) | 2300 or 2400 | ||
| Fuel Tank | Volume(L) | 150 | |
| Transmission System | Clutch | Single,Dry,Dual Stage Type | |
| Gear Box | F16+R8/F16+R8(creeper gear) | ||
| Differential | Closed 4-planetary Gears | ||
| Differential Lock | Mechanical Sliding Sleeve | ||
| Braking System | Wet Double Plate Disc Brake | ||
| Running System | Tyre Model | F/R(2WD) | 6.5—20/16.9—34 |
| F/R(4WD) | 11.2—24/16.9—34 | ||
| Steering System | Hydraulic Wheel Steering | ||
| Working Device | Hydraulic System Type | Positive lifter | |
| Linkage Type | II Rear Mount 3-point Linkage | ||
| PTO(Standard) | φ38,8teeth φ35,6teeth | ||
| PTO Speed(r/min) | 540/1000 | ||
| Drawbar Type | Fixed Drawbar/Swing Drawbar | ||
| Optional configuration | |||
| Cab | AC | Heater | Air-brake |
| Adjustable Seat | Multiple Unit Valve | ROPS | Sunvisor |
| Double Crush Lifter | Radio | CD Player | Paddy Tyre |
| Bob-weight | Frontballest |
11×20=220kg 20kg/pcs |
|
| Rearballast |
2×80=160kg 80kg/pcs |
||
| Paddy Tyre | F/R | 11.2—24/12.4—24 | |
| F/R(optional) | 13.6—28/16.9—34 | ||
