Product Descriptions
| Model | DW120NC | |
|
Max. Bending Capacity |
○ round | MS:φ133×8mm;SS: φ120×7mm |
| □ Square | 90×90×5mm | |
| ┗ angle steel | 90 mm | |
| ▭ rectangle | 60×120mm | |
| ● rod | Φ80mm | |
| ■ Square rod | 70×70mm | |
| Bending method | Hydraulic | |
| Operate mode | Manual, semi auto, | |
| Feeding, rotate and adjust angle | automatic | |
| driving axle | rack | |
| Fit to Shapes | Round tube, square tube, elliptical tube, plum blossom-shape tube, shaped tube, U-steel, angle steel, I-steel and flat steel, etc | |
| Adapted material | steel pipe, stainless steel, copper pipe, aluminum pipe,and multiple-unit tube | |
| System language | Chinese, English, Spanish, Russian, or as requirement | |
| Max Length of bending pipe | Unlimited | |
| Feeding speed | 1.1 m/sec | |
| Feeding precession | ±0.1 | |
| Max R for bending | R50-R450mm | |
| Max angle for bending | 190° | |
| Bending precession | ±0.1° | |
| Bending speed | 30°/sec | |
| Angle precision | ±0.1° | |
| Power for motor | 17Kw | |
| Oil Tank Capacity | 260 KG | |
| Max oil temperature | 60° | |
| cooling method | Air or water cold | |
| operating mode | button and touch screen | |
| Maximum number of stored bending programs | 200 sets | |
| Max number of elbow pipe each program | 16 sets | |
| Overall size (L×W×H) | 6.5×1.1×1.4 m | |
| Weight | 5600kg | |
