Product Descriptions
| Model | DW114NC | |
|
Max. Bending Capacity |
○ round | MS:φ115×8mm;SS: φ89×7mm |
| □ Square | 80×80×5mm | |
| ┗ angle steel | 85mm | |
| ▭ rectangle | 60×110mm | |
| ● rod | Φ75mm | |
| ■ Square rod | 60×60mm | |
| Operate mode | Manual, semi auto, | |
| Feeding, rotate and adjust angle | manual | |
| Fit to Shapes | Round tube, square tube, elliptical tube, plum blossom-shape tube, shaped tube, U-steel, angle steel, I-steel and flat steel, etc | |
| Adapted material | steel pipe, stainless steel, copper pipe, aluminum pipe,and multiple-unit tube | |
| System language | Chinese, English, Spanish, Russian, or as requirement | |
| range of bending radius | R50-R550mm | |
| Max bending angle | 190° | |
| Bending precession | ±0.1° | |
| Bending speed | 30°/sec | |
| voltage | 380/415 or as requirement | |
| Total power | 12 KW | |
| Oil Tank Capacity | 300L | |
| Hydraulic oil | antiwear hydraulic oil | |
| Standard Oil pressure | 21 MPA | |
| Max oil temperature | 50° | |
| cooling method | Air-cooled or Water-cooled | |
| operating mode | button , touch screen, footswitch | |
| Maximum number of stored bending programs | 20 | |
| Max number of elbow pipe each program | 20 | |
| Oversize | 5.6×1.35×1.55M | |
| weight | 5.3 T | |
