Product Descriptions
50 HP Tractor, 50 Horsepower Tractor, Cheap Compact Tractor
Characteristic
(1) Direct injection diesel engine, fuel-efficient and durable good maintenance;
(2) Dual stage clutch,8F+2R gearshift, flat deck available,easy to operate;
(3) Adopt Laidong engine, Chinese famous diesel engine , quality assurance;
(4)Rear three-point suspension, multi way valve, equipped all kinds of the farm implement
(5)Streamlined design, novel and beautiful appearance
| Model | 454 | 504 | 604 | |
| Engine | Horsepower(HP) | 45 | 50 | 60 |
| Engine brand | YTO,Laidong,Weilai | |||
| Cylinder Quantity | 4 cylinders | |||
| Engine rated speed（r/min） | 2400 | |||
| Working device | Wheel Driver | 4WD | ||
| Max traction(KN) | ≥6 | ≥7 | ≥8 | |
| Max lifting force(KN) | ≥7.5 | ≥10.6 | ≥12 | |
| Tillage depth adjustment | Strong lift and strong drop | |||
| Hydraulic output device | 1 groups of hydraulic output | |||
| PTO Speed(r/min) | 540/760 Rpm | |||
| Suspension device type | Front/Rear mounted suspension | |||
| Suspension device category | Post Positioned Tri-point Suspension | |||
| Walking device | Max speed (km/h) | 40km/h | ||
| Gear Shifts | TYE8+2/8+8 shuttle shift | |||
| Clutch | single-stage type | |||
| Gear shift type | TYE8+2/8+8 shuttle shift | |||
| Steering type | Hydraulic steering gear | |||
| Brake type | Hydraulic brake | |||
| Tyre Size(F/R) | F6.0-16 R9.5-24 | |||
| Mini clearance (mm) | 330 | |||
| Wheel base (mm) | 1680 | 1510 | 1800 | |
| Front wheel tread(mm) | 600-1600 | |||
| Rear wheel tread(mm) | 950-2400 | |||
| F/R Counterweight(kg) | 78/180 | |||
| Weight(kg ) | 1650 | 1700 | 1750 | |
| Dimensions (L*W*H)(mm) | 3050x1300x2000 | 3100×1400×2050 | 3140x1500x2200 | |
