Product Descriptions
Tractors have many function in agriculture, such as it can plow subsoiling, can spray,harvest the grain,can transport goods with a trailer,can be used for farmland planting with rotary tiller, etc.
| SPECIFICATIONS FOR 60 HP TRACTORS | ||
| (mm)Dimensions of tractor | Length (to front ballast) | 3900mm |
| Width | 1795mm | |
| Height (to the exhaust vent) | 2160mm | |
| Tread | 1300mm-1500mm | |
| Axle Base | 2072mm | |
| Min.Ground Clearance | 410mm | |
| Engine | Model | QC4102 |
| Type | Vertical Water Cooledand 4-stroke | |
| Rated Power(kw) | 44.1KW | |
| Rated speed (r/min) | 2400 | |
| Fuel | Diesel Oil | |
| Tire | Front Wheel | 8.3-20 |
| Rear Wheel | 12.4/28 | |
| Structure weight (kg) | 2600Kg | |
| Clutch | Dry-friction,single stage or Dry-friction,Two Stage | |
| Steering | Hydraulic Type | |
| Transmission Type | 12+12 shuttle gear | |
| Suspension Type | Rear three-point suspension Class I | |
| PTO | Type and Rev | 540/760 or 540/1000 |
| Spline Size | I38 Rectangle Spline With 8 teeth (8x28.91x38x8.69) | |
Main Features
1).Engine:Quanchai/Xinchai, 4 Cylinders
2).4*4 wheel drive, 60hp
3).Full Hydraulic Steering
4).With Dual-Stage Clutch
5).12+12 shuttle gear
6).3-point linkage
7).Dual-Speed PTO
8).Tires: 8.3-20/12.4-28
Option:
1)Front ballast
2)Rear ballast
3)Air brake
4)ROPS
5)Canopy
6)Multi-way valve
7)Standard Cabin
8)Heater
9)A/C
10)Swing draw bar
11)You can select all kinds of accessories for this tractor,like front loader, backhoe and so on.
