Product Descriptions
|
Model
|
DW89NC
|
|
|
Max. Bending Capacity |
○ round
|
MS:φ89×6mm;SS: φ76×5mm
|
|
Square
|
70×70×4mm
|
|
|
angle steel
|
80 mm
|
|
|
▭ rectangle
|
50×80mm
|
|
|
rod
|
Φ60mm
|
|
|
Square rod
|
50×50mm
|
|
|
Operate mode
|
Manual, semi auto,
|
|
|
Feeding, rotate and adjust angle
|
manual
|
|
|
Fit to Shapes
|
Round tube, square tube, elliptical tube, plum blossom-shape tube, shaped tube, U-steel, angle steel, I-steel and flat steel, etc
|
|
|
Adapted material
|
steel pipe, stainless steel, copper pipe, aluminum pipe,and multiple-unit tube
|
|
|
System language
|
Chinese, English, Spanish, Russian, or as requirement
|
|
|
range of bending radius
|
R50-R450mm
|
|
|
Max bending angle
|
190°
|
|
|
Bending precession
|
±0.1°
|
|
|
Bending speed
|
30°/sec
|
|
|
voltage
|
380/415 or as requirement
|
|
|
Total power
|
11 KW
|
|
|
Oil Tank Capacity
|
260 L
|
|
|
Hydraulic oil
|
antiwear hydraulic oil 46#
|
|
|
Standard Oil pressure
|
21 MPA
|
|
|
Max oil temperature
|
60°
|
|
|
cooling method
|
Air-cooled or Water-cooled
|
|
|
operating mode
|
button , touch screen, footswitch
|
|
|
Maximum number of stored bending programs
|
20
|
|
|
Max number of elbow pipe each program
|
20
|
|
|
size
|
4.2×1.2×1.3M
|
|
|
weight(KG)
|
4300
|
|
