Product Descriptions
| Model (DW) | DW 89 CNC | |
| Max. Bending Capacity(mm)(diameter)(thickness) | o round (MS) | 89×86 |
| o round (SS) | 76×85 | |
| square | 70×70×84 | |
| angle steel | 70×84 | |
| rectangle | 50×80×84 | |
| ●rod | 060 | |
| square rod | 50×50 | |
| max length of through mandrel(m) | 1.7 | |
| Max R for bending(mm) | R25-R200 | |
| Max bending angle | 220° | |
| Bending precession | ±0.1° | |
| Bending speed | 70°/sec | |
| Total power (Kw) | 4.0 | |
| lowest operating oil-level (L) | 140 | |
| Overall size (LxWxH) (m³) | 2.6×0.7×1 | |
| Weight(KG) | 1000 | |
| Bending method | hydraulic | |
| Operating mode | manual, semi auto (button, touch screen, footswitch) | |
| Feeding, rotate , adjust angle | manual | |
| cooling method | air or water cold | |
| Maximum number of storedbending programs | 200 | |
| Max number of elbow pipe eachprogram | 20 | |
| Standard Oil pressure (KP) | 16 | |
| Max oil temperatureallowed(℃) | 60 | |
| Bending shape | Round tube, square tube, elliptical tube, plum blossom-shape tube, shaped tube, U-steel,angle steel, I-steel and flat steel, etc | |
| Adapted material | steel pipe, stainless steel, copper pipe, aluminum pipe, and multiple-unit tube | |
