Product Descriptions
Model: DF-Hand Tractor Tiller
Engine type: high-efficiency diesel engine
Power: 12/15/18/20/22 horsepower
In the table below, we will introduce the relevant parameters of our products in detail. Of course, if you have any questions, you can consult us directly.
| Hand Tractor Tiller Technical Parameter | ||||||
| Model(with Power tiller) | DF12 | DF15 | DF18 | DF20 | DF22 | |
| Weight(kgs) | Without Rotary Tiller | 360 | 371 | 371 | 396 | 401 |
| With Rotary Tiller | 490 | 515 | 515 | 540 | 545 | |
|
Turning speed of Rotary Tiller shaft(Rpm) |
Low | 188 | 188 | 188 | 188 | 188 |
| High | 300 | 300 | 300 | 300 | 300 | |
| Overall dimensions(L*W*H)(cm) | 268*96*125 | 268*96*125 | 268*96*125 | 268*96*125 | 268*96*125 | |
| Number of blades(pcs) | 18 | 24 or 26 | 24or 26 | 24or 26 | 24or26 | |
| Rototiller width(mm) | 600 | 900 | 900/1000 | 900/1000 | 900/1000 | |
| Type of tractor | Single axle,dual-purpose for both tractorand drive | |||||
| Traveling Speed(km/h) | Forward | 1.4,2.5,4.1,5.3,9.4,15.3 | ||||
| Reverse | 1.1,3.8 | |||||
| Tyre size | 600-12 | 600-12 | 600-12 | 600-12 | 600-12 | |
| Wheel track(mm) | 800,740,640580(Standard 800) | |||||
| Min.groundclearance(mm) | 185 | |||||
| Model ofengine | ZS195NL | ZS1100NL | ZS1105NL | ZS1110NL | ZS1115NL | |
| Type of engine | Single cylinder,Horizontal,4-stroke,directly injection,With oil bath longair filter | |||||
Our two-wheel Hand Tractor Tiller is highly versatile and can be equipped with a range of attachments, making it suitable for various agricultural tasks and ensuring maximum productivity in different farming scenarios.
| Borex stroke(mm) | 95*115 | 100*115 | 105*115 | 110*115 | 115*115 | |
| Total displacement(L) | 0.815 | 0.903 | 0.996 | 1.093 | 1.194 | |
| Compression ratio | 17:1 | |||||
| Turing speedof crankshaft | 2200 | |||||
| 1-hour rated output(kw/hp) | 10.6kw/14hp | 12.1kw/16hp | 13.2kw/18hp | 14.7kw/20hp | 30kw/22hp | |
| 12-hour rated output(kw/hp) | 8.82kw/12hp | 11.03kw/15hp | 11.76kw/16hp | 13.23kw/18hp | 14.7kw/20hp | |
