Product Descriptions
| Model |
8HP Walking tractor |
10HP Walking tractor |
11HP Walking tractor |
12HP Walking tractor |
13HP Walking tractor |
15HP Walking tractor |
18HP Walking tractor |
20HP Walking tractor |
22HP Walking tractor |
| Diesel engine |
ZR180 8HP |
ZR190 10HP |
ZR192 11HP |
ZR195 12HP |
ZR196 13HP |
ZS1100 15HP |
ZS1105 18HP |
ZS1110 20HP |
ZS1115 22HP |
| Engine Type | Single, horizontal, water cooled,four stroke | ||||||||
| Starting method | Hand start /Electric start | ||||||||
| Combustion System | Direct injection | ||||||||
| Cooling way | Evaporative/Condensing | ||||||||
|
Power (1 hour ) |
5.88kw /8hp |
7.92kw /10hp |
8.47kw /11.5hp |
9.68kw /13hp |
9.92kw /13.5hp |
12.13kw /16hp |
13.31kw /18hp |
14.56kw /20hp |
16.17kw /22hp |
|
Power (12 hour ) |
5.35kw /8hp |
7.0kw /9.5hp |
7.7kw /11hp |
8.8kw /12hp |
9.5kw /13hp |
11.03kw /15hp |
12.1kw /16hp |
13.24kw /18hp |
14.7kw /20hp |
| Dimensions(LxWxH) | 2170×890×1150mm | 2680×960×1250mm | |||||||
| Min.Ground Distance | 210mm | 185mm | |||||||
| Parameter | Tread:640-800mm,Clutch:Sing/double friction disc of constant conjunction,6 pieces Forward gear,2 pieces Reverse gear.Tyre:6.00-12 | Tread:580-600mm,Tyre:6.00-12,Weight 350kg | |||||||
| Tire Pressure | Field Work: 80~200(0.8~2.0kgf/cm2) | ||||||||
| Transportation Work:140~200(1.4~2.0kgf/cm2 ) | |||||||||
| Triangle belt | 2 pcs or 3 pcs B1750 | 3 pcs B1800 | 2 pcs or 3 pcs B1850 | 4 pcs B1880 | |||||
service
1, Training how to install the machine, training how to use the machine, free technical support for lifetime.
2, Warranty period of one year since machine arrives destination port. Our machine adopts modular design, if there have any damaged parts we will send you the free part, you just need pay the freight.
3, Big order, OEM for Module replacement even product design.
4, Engineers available to service overseas for Major clients.
